73TST – Sealed Dome Head | Stainless Rivet | Stainless Mandrel

The Sealed or Closed End Rivet, when set produces a seal that prevents the passage of liquid or vapor at pressures up-to 100 psi. The seal is possible thanks to the unique cup-shaped design and complete retention of the rivet mandrel within the rivet body. All of these features contribute to a greater Tensile Strength than the Standard Rivet equivalent, making this series the ideal solution when seeking a weather proof join. Available in a wide combination of diameters, grip ranges and materials, the Sealed Rivet Series are a highly versatile and proven system with an extensive selection of hand, air and battery powered setting tools.

Rivet Measurement Method and Post Install Sequence

A = Rivet Diameter | B = Rivet Length | C = Head Diameter | D = Head Thickness | E = Mandrel Diameter

Rivtec® Sealed Rivet Series

For more information and technical data click on the Product Download, free phone in NZ 0800 RIVTEC or email sales@rivtec.co.nz

73TST Series Download

General Applications and Industries Include:

• Sheetmetal Fabrication

• Aerospace

• Automotive

• Signage

• Boating and Marine

• Engineering

• Truck Bodies

• Trailers

• Coolstore & Refrigeration

• Air Conditioning

Read more
Add to wishlist

Description

73TST – Sealed Dome Head | Stainless Rivet | Stainless Mandrel

The Sealed or Closed End Rivet, when set produces a seal that prevents the passage of liquid or vapor at pressures up-to 100 psi. The seal is possible thanks to the unique cup-shaped design and complete retention of the rivet mandrel within the rivet body. All of these features contribute to a greater Tensile Strength than the Standard Rivet equivalent, making this series the ideal solution when seeking a weather proof join. Available in a wide combination of diameters, grip ranges and materials, the Sealed Rivet Series are a highly versatile and proven system with an extensive selection of hand, air and battery powered setting tools.

Rivet Measurement Method and Post Install Sequence

A = Rivet Diameter | B = Rivet Length | C = Head Diameter | D = Head Thickness | E = Mandrel Diameter

Rivtec® Sealed Rivet Series

For more information and technical data click on the Product Download, free phone in NZ 0800 RIVTEC or email sales@rivtec.co.nz

73TST Series Download

General Applications and Industries Include:

• Sheetmetal Fabrication

• Aerospace

• Automotive

• Signage

• Boating and Marine

• Engineering

• Truck Bodies

• Trailers

• Coolstore & Refrigeration

• Air Conditioning

Reviews (0)

Be the first to write a review

Additional info

SKU: 73TST
Availability: Usually ships in 24 hours
Shipping: Calculated at Checkout
Rivet Body / Mandrel: 304 Stainless / 304 Stainless
Rivet Head Style: Dome
Diameters Available: 3.20 and 4.80mm
